ALTA Wireless Infrared Motion Sensor - AA Powered, 900MHZ

MonnitSKU: MNS2-9-W2-MS-IR



Motion sensors use passive infra-red (PIR) technology to monitor for a variety of different needs. The 60° beam width is best for use in typical security types of monitoring. Human bodies or med/large sized animals can be detected at a range of up to 5 meters, alerting you when someone (or something) is where it shouldn’t be. Use the 100° version of the sensors for tracking applications. Designed to be placed under a desk, a cubicle, a conference room table, the sensor can be implemented by companies as part of room scheduling and space booking programs, showing what desks are available/unoccupied within a building, how effectively space is being utilized or underutilized, etc.

Monnit MNS2-9-W2-MS-IR Features

  • 1,200+ foot range
  • 12+ year battery life
  • 80+ wireless sensors
  • Bank-level AES security
  • Up in 15 easy setup
  • Global ready (900, 920, 868 & 433 MHz)
  • Infrared Motion Sensing Element Specifications

  • Current Consumption: Type: 170 µA Max: 300 µA
  • Wake-up Time: 30 Seconds
  • Variation Specifications

  • Sensing Range: 15 ft (4.5 m)/12 ft (3.7 m)/9 ft (2.7 m)
  • Security: Encrypt-RF® (256-bit key exchange and AES-128 CTR)
  • Weight: 2.9 oz. (82.21 g)
  • Supply Voltage: 2.0–3.8 VDC (3.0–3.8 VDC using power supply)
  • Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F)
  • Data Logging (iMonnit Premiere): Datalogs 2000 to 4000 readings if gateway connection is lost (non-volatile flash, persists through the power cycle): 10-minute heartbeats = ~ 22 days2-hour heartbeats = ~ 266 days
  • Sensing Method: Quad Array Passive Infrared (PIR) Sensing Element
  • Response Time: 1 to 3 Seconds
  • Storage Temperature:: -40°C to 85°C (-40°F to 185°F)
  • Visual Confirmation: Standard LensViewing Angle: 60°Range: 15ft (4.57m)/12ft (3.65 m)/9ft. (2.74 m)
  • Visual Confirmation: Wide-Angle LensViewing Angle: 100°Range: 15ft. (4.57m)/12ft. (3.65m)/9ft. (2.74m)
  • ALTA AA Specifications

  • Battery Type: 2 Replaceable AA 1.5 V Batteries
  • Dimension: 4.375 in x 2.470 in x 1.12 in
  • Supply Voltage: 2.0 - 3.8 V (2 x AA 1.5V Batteries or Optional Power Supply)
  • Battery Life: At 1 hour heartbeat setting, AA batteries will last up to 10 years.**
  • Max Operating Temperature Using AA Alkaline: -18°C to 55°C (0°F to 130°F)
  • Max Operating Temperature Using AA Lithium: -40°C to 60°C (-40°F to 140°F)
  • Optimal Battery Operating Temperature: +10°C to +50°C (+50°F to +122°F)
  • Enclosure Material: ABS
  • ALTA 900 MHz Specifications

  • Operating Frequency: 900 MHz Operating Frequency
  • Certifications: Complies with Part 15 of the FCC Rules. (FCC ID: ZTL-G2SC1)Complies with Industry Canada standards. (IC: 9794A-G2SC1)
  • Device Range: Device Range Up to 1,200 ft. non-line-of-sight, wireless device range*
  • Security: Encrypt-RF® (Diffie-Hellman Key Exchange + AES-128 CBC)
